Model No.︰POM GH-20
Brand Name︰Fukuang
Country of Origin︰China
Unit Price︰US $ 4 / KG
Minimum Order︰25 KG
Key Specifications/Special Features:
Polyplastics POM duracon GH-20 acetal co-polymer
POM GF 20% reinforced, high strength, high rigidity
Physical properties | Metric | English | Comments |
Density | 1.54g/cc | 0.0556lbs/in³ | ISO 1183 |
Filler content | 20% | 20% | Glass fiber |
Mechanical properties | Metric | English | Comments |
Tensile strength, ultimate | 100MPa | 14,500psi | ISO 527-1, 2 |
Elongation at break | 2.00% | 2.00% | ISO 527-1, 2 |
Flexural strength | 135MPa | 19,600psi | ISO 178 |
Flexural modulus | 6.00GPa | 870ksi | ISO 178 |
Charpy impact, notched | 0.520J/cm² | 2.47ft-lbs/in² | ISO 179/1eA |
Thermal properties | Metric | English | Comments |
Deflection temperature at 1.8MPa (264psi) | 158°C | 316°F | ISO 75-1, 2 |
Flammability, UL94 | HB | HB |
Payment Terms︰ 30% in advance ,balance 70% before delivery
